Ubiquiti UniFi U7 Pro XG WiFi 7 Tri Band Access Point with 10 GbE Uplink, 2x2 MU MIMO per Band, 5.8 Gbps 6 GHz Speed, 300+ Clients, PoE+ Powered Ceiling / Wall Mount Design, White | U7-Pro-XG

Dimensions

Ø206 x 32.5 mm (Ø8.1 x 1.3")

WiFi Standard

WiFi 7

Spatial Streams

6

Coverage Area

140 m² (1,500 ft²)

Max. Client Count

300+

Uplink

10 GbE

Mounting

Ceiling, Wall (Lite Mount Included)

Power Method

PoE+

MIMO

6 GHz: 2x2 (DL/UL MU-MIMO)5 GHz: 2x2 (DL/UL MU-MIMO)2.4 GHz: 2x2 (DL/UL MU-MIMO)

Max. Data Rate

6 GHz: 5.8 Gbps (BW320)5 GHz: 4.3 Gbps (BW240)2.4 GHz: 688 Mbps (BW40)

Antenna Gain

6 GHz: 6 dBi5 GHz: 5 dBi2.4 GHz: 4 dBi

Max. TX Power

6 GHz: 24 dBm5 GHz: 26 dBm2.4 GHz: 23 dBm

Max. BSSIDs

8 per Radio

Supported Data Rates

802.11be (WiFi 7): 7.3 Mbps–5.8 Gbps802.11ax (WiFi 6): 7.3 Mbps–2.4 Gbps802.11ac (WiFi 5): 6.5 Mbps–1.7 Gbps802.11n: 6.5 Mbps–300 Mbps

Wireless Meshing

Yes

Band Steering

Yes

802.11v / 802.11r / 802.11k

Yes

Advanced Radio Management

Yes

Passpoint (Hotspot 2.0)

Yes

Captive Portal / Branding / Voucher / Payment / External Server

Yes

Password Authentication

Yes

Guest Network Isolation

Yes

PPSK / Speed Limit / Device Isolation

Yes

WiFi Schedules

Yes

RADIUS over TLS (RadSec)

Yes

Dynamic VLAN

Yes

Max. Power Consumption

22W

Voltage Range

42.5—57V DC

Networking Interface

(1) 10 GbE RJ45 port

Weight

750 g (1.7 lb)

Management

Ethernet

Enclosure Material

UV-stabilized polycarbonate, aluminum alloy

Mount Material

Stainless steel (SUS304), galvanized steel (SGCC)

LEDs

System (White/Blue)

Channel Bandwidth

HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 MHz

NDAA Compliant

Yes

Certifications

CE, FCC, IC

Operating Frequency (US/CA)

2400–2472 MHz5150–5850 MHz5925–7125 MHz

Operating Frequency (Worldwide)

2400–2483.5 MHz5150–5725 MHz5925–7125 MHz

Temperature

-30 to 40°C (-22 to 104°F)

Humidity

5–95% noncondensing

Application Requirements

UniFi Network v9.0.114+ (U7 Pro XG – White)
