Ubiquiti Networks UniFi U6 In-Wall Access Point & 4-Port PoE Gigabit Switch 5.3 Gb/s Throughput, 1 x Gigabit PoE Uplink, In-Wall Mount, White | U6-IW - Image 1
1 / 7

Ubiquiti Networks UniFi U6 In-Wall Access Point & 4-Port PoE Gigabit Switch 5.3 Gb/s Throughput, 1 x Gigabit PoE Uplink, In-Wall Mount, White | U6-IW

Brand: Ubiquiti|Category: Access points|SKU: 11050|Model: U6-IW
AED 684.00AED 699.002% OFF

You save AED 15

  • WiFi 6

  • 6 spatial streams

  • 300+ connected devices

  • 115 m² (1,250 ft²) coverage

  • Powered using PoE/PoE+*

  • (4) GbE ports with (1) PoE output

Ubiquiti UniFi U6 In-Wall (U6-IW) is a compact Wi-Fi 6 in-wall access point that upgrades a room with strong wireless coverage while providing convenient wired connectivity through built-in Gigabit Ethernet ports. Ideal for offices, hotels, and residential rooms, it supports UniFi centralized management and seamless roaming for a clean, professional setup.

Included warranty

1 Year

Secure payment

Your payment is encrypted and processed securely at checkout.

Additional Warranty

1

Options Available:

Product Description

Ubiquiti UniFi U6-IW



In-Wall Access Point

Specification



Category

Specification

Mechanical



Dimensions

139.7 x 96 x 31.2 mm (5.5 x 3.8 x 1.3")

Weight

460 g (1 lb)

Enclosure Material

Plastic, aluminum

Mount Material

Aluminum

Hardware



Networking Interface

(1) Data-in: GbE RJ45 port
(4) Data-out: GbE RJ45 ports

Management Interface

Ethernet, Bluetooth

PoE Interface

(1) PoE in (PoE output not used)
(1) PoE out (Requires a PoE+ switch)

Power Method

PoE+ (Required for PoE output)

Power Supply

UniFi PoE switch
48V, 0.5A PoE adapter (Optional)

Max. Power Consumption

13W (Excluding PoE output)

Max PoE Wattage per Port by PSE

15.4W*
*Requires a PoE+ switch

Voltage Range PoE Mode

44—57V DC

Max. TX Power

2.4 GHz: 22 dBm
5 GHz: 26 dBm
6 GHz: –

MIMO

2.4 GHz: 2 x 2 (DL/UL MU-MIMO)
5 GHz: 4 x 4 (DL/UL MU-MIMO)
6 GHz: –

Max. Data Rate

2.4 GHz: 573.5 Mbps (BW40)
5 GHz: 4.8 Gbps (BW160)
6 GHz: –

Antenna Gain

2.4 GHz: 5 dBi
5 GHz: 5.9 dBi
6 GHz: –

LED

White/blue

Button

Factory reset

Mounting

Wall (Included)

Ambient Operating Temperature

-30 to 60° C (-22 to 140° F)

Ambient Operating Humidity

5 to 95% non-condensing

Certifications

CE, FCC, IC

Software



WiFi Standards

802.11a/b/g/n/ac/ax (WiFi 6)

Wireless Security

WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)

BSSID

8 per radio

VLAN

802.1Q

Advanced QoS

Per-user rate limiting

Guest Traffic Isolation

Supported

Concurrent Clients

300+

Zero-Wait DFS

Yes*
*Supported with upcoming firmware versions.

Supported Data Rates

802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
802.11ac: 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6): 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)

Application Requirements

UniFi Network: Version 6.4.52 and later
