SAMSUNG 9100 PRO Heatsink PCIe 5.0 NVMe M.2 Internal SSD, 1TB Capacity, V-NAND TLC Type, Up to 14,700 MB/s Sequential Read & Up to 13,300 MB/s Sequential Write, TRIM & SMART Support | MZ-VAP1T0CW

Article Name

9100 PRO Heatsink PCIe® 5.0 NVMe™ M.2 SSD - 1TB

Form Factor

M.2 (2280)

Capacity

1TB

Storage Type

Samsung V-NAND TLC

Controller

Samsung in-house controller

Cache Memory

Samsung 4GB Low Power DDR4X SDRAM

Connectivity

PCIe® 5.0 x4, NVMe™ 2.0

Device Dimensions

80.15 x 25 x 8.88 mm (max.)

Weight

30.0 g

Power Consumption (Operation)

Read: 9.0W / Write: 8.2W

Power Consumption (Idle)

6.5 mW

Power Consumption (Device Sleep)

5.7 mW

Operating Voltage

3.3V ± 5%

Reliability (MTBF)

1.5 million hours

Operating Temperature

0°C to 70°C

Shock Resistance

1,500 G duration & 0.5 m/sec. (half sine)

Sequential Read Speed

Up to 14,800 MB/s

Sequential Write Speed

Up to 13,400 MB/s

Random Read

Up to 2,200,000 IOPS

Random Write

Up to 2,600,000 IOPS

TRIM Support

Yes

SMART Support

Yes

Garbage Collection

Auto Garbage Collection Algorithm

Encryption

AES 256-bit (Class 0), TCG/Opal IEEE1667

WWN Support

No

Device Sleep Mode

Yes

Software

Magician software for SSD management

Application

Client PCs, Game Consoles

Installation Accessories

No
