Lenovo ThinkPad X1 Carbon Gen 13 Laptop, 14" 2.8K OLED 120Hz Display, Intel Core Ultra 7 258V, 32GB RAM, 512GB SSD, Intel Arc Graphics 140V, Backlit English KB, Windows 11 Pro, Black | 21NS0014US

Model Information

Model

21NS0014US

Country/Region

USA

Performance

Processor

Intel® Core™ Ultra 7 258V, 8C (4P + 4LPE) / 8T, Max Turbo 4.8GHz, 12MB Cache

AI PC Category

Copilot+ PC

NPU

Integrated Intel® AI Boost, up to 47 TOPS

Graphics

Integrated Intel® Arc™ Graphics 140V

Chipset

Intel® SoC Platform

Memory

32GB Soldered LPDDR5x-8533, MoP (dual-channel, non-upgradable)

Max Memory

32GB (soldered)

Storage

512GB SSD M.2 2280 PCIe® 5.0x4 NVMe® Opal 2.0

Storage Support

One drive, up to 2TB M.2 2280 SSD

Storage Slot

One M.2 2280 PCIe® 5.0 x4 (V or H series CPUs only)

Audio Chip

Realtek® ALC713 HD Audio (for V series processor)

Speakers

Stereo, 2W x2, Dolby Atmos®

Camera

FHD 1080p + IR Discrete, Privacy Shutter

Microphone

Dual 360°

Battery

57Wh

Power Adapter

65W USB-C® Slim GaN (2-pin)

Design

Display

14" 2.8K (2880x1800) OLED, 400 nits, Anti-glare/Anti-reflection/Anti-smudge, 100% DCI-P3, 120Hz, HDR True Black 500, Dolby Vision®

Touchscreen

No

Keyboard

Backlit, English

Touchpad

Trackpad

Case Color

Black (Painted)

Case Material

Carbon Fiber (Top), Magnesium (Bottom)

Pen Support

Not Supported

Dimensions (WxDxH)

312.80 x 214.75 x 8.08–14.37 mm (front/rear), Max: 16.95 mm / 12.31 x 8.45 x 0.32–0.56 in, Max: 0.67 in

Weight

Starting at 986 g (2.17 lbs)

Software

Operating System

Windows® 11 Pro (English - US / UK)

Bundled Software

Intel® Connectivity Performance Suite, Lenovo® AI Now

Connectivity

WLAN + Bluetooth

Intel® Wi-Fi 7 BE201 (802.11be 2x2) + Bluetooth 5.4

Ethernet

Not Available (No onboard)

WWAN

Not Supported

SIM Card

None

NFC

None

Ports

2x USB-A 3.2 Gen 1 (5Gbps, 1 Always On), 2x USB-C (Thunderbolt 4 / USB4 40Gbps) with PD 3.0 and DisplayPort 2.1, 1x HDMI 2.1, 1x 3.5mm Audio Combo Jack

Optional Ports

None

Docking Support

Thunderbolt™ / USB-C® docking

Security & Privacy

Security Chip

Discrete TPM 2.0

Fingerprint Reader

Touch Style, Match-on-Chip (in Keyboard Key)

Physical Locks

Kensington® Nano Security Slot™ (2.5 x 6 mm)

Other Security

Camera Privacy Shutter, IR Camera (Windows Hello Facial Recognition)

Manageability

System Management

Non-vPro®

Service

Base Warranty

1-year, Courier or Carry-in

Included Upgrade

None

Accessories

Bundled Accessories

None

Certifications

Green Certifications

ENERGY STAR® 8.0, EPEAT™ Gold, RoHS, ErP Lot 6/26, TCO Certified 10.0

Other Certifications

Eyesafe® Certified 2.0, Intel® Evo™ Platform, SGS High Performance AI PC Certification

Mil-Spec Test

MIL-STD-810H Passed
