GIGABYTE B850 Force AM5 Micro ATX Motherboard, AMD B850 Chipset, 2x DDR5 DIMM Slots, 128GB Max Memory, 1x PCIe 5.0 x16 Slot, 3x M.2 Slots | B850M-FORCE

CPU

AMD Socket AM5; supports Ryzen™ 9000 / 8000 / 7000 Series

Chipset

AMD B850

Memory

2 x DDR5 DIMM up to 128 GB (64 GB per DIMM)

DDR5 9600(OC)/9200(OC)/8800(OC)/8600(OC)/8400(OC)/8200(OC)/8000(OC)/7800(OC)/7600(OC)/7200(OC)/7000(OC)/6800(OC)/6666(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5600(OC)/5200/4800/4400 MT/s

Dual channel, non-ECC Un-buffered DIMM support

AMD EXPO™ and XMP profiles supported

Onboard Graphics

1 x HDMI 4096x2160@60 Hz (HDMI 2.1, HDCP 2.3, HDR)

1 x DisplayPort 3840x2160@144 Hz (DP 1.4)

Audio

Realtek® Audio CODEC; High Definition Audio 2/4/5.1/7.1-channel

LAN

Realtek® 2.5GbE LAN (2.5/1/0.1 Gbps)

Expansion Slots

CPU: 1 x PCIe x16 slot (PCIe 5.0 x16 for Ryzen 9000/7000; PCIe 4.0 x8/x4 for 8000 Phoenix series)

Chipset: 1 x PCIe 4.0 x16 slot (x4 speed)

Storage Interface

1 x M.2 (M2A_CPU, PCIe 5.0/4.0 x4/x2 SSDs)

1 x M.2 (M2B_CPU, PCIe 4.0 x4/x2 or x2 SSDs)

1 x M.2 (M2C_SB, PCIe 4.0 x2 SSDs)

4 x SATA 6Gb/s

RAID 0,1,5,10 support for NVMe (RAID 5 on Ryzen 9000 only); RAID 0,1,10 for SATA

USB

CPU: 1 x USB-C 3.2 Gen1, 1 x USB 3.2 Gen2 Type-A (red), 1 x USB 2.0/1.1 (rear)

Chipset: 1 x USB-C 3.2 Gen1 (internal), 4 x USB 3.2 Gen1 (2 rear, 2 internal), 5 x USB 2.0/1.1

Internal I/O

24-pin ATX, 8-pin 12V, CPU/system fan headers, 3x ARGB Gen2, 1x RGB LED, 3x M.2, 4x SATA, TPM, USB headers, reset, Q-Flash Plus, Clear CMOS jumper

Back Panel I/O

1x HDMI, 1x DisplayPort, 1x PS/2, 1x USB-C 3.2 Gen1, 2x USB 3.2 Gen1, 1x USB 3.2 Gen2 (red), 2x USB 2.0, 1x RJ-45, 3x audio jacks, Q-Flash Plus button

I/O Controller

iTE® I/O Controller Chip

Hardware Monitoring

Voltage, Temperature, Fan Speed, Water Cooling Flow, Fan Fail Warning, Fan Speed Control

BIOS

256 Mbit flash, AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Features

GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, Smart Backup

Bundled Software

Norton® Internet Security (OEM)

Operating System

Windows 11 64-bit, Windows 10 64-bit

Form Factor

Micro ATX, 24.4 x 24.4 cm
