GIGABYTE B760 DS3H WIFI6E GEN5 LGA 1700 ATX Motherboard, Intel B760 Chipset, 4x DDR5 DIMM Slots, 256GB Max Memory, 1x PCIe 5.0 x16, 2x M.2 Slots, WIFI 6E & BT 5.3 | B760-DS3H-WF6E-GEN5

CPU

LGA1700 socket, supports 14th/13th/12th Gen Intel® Core™, Pentium® Gold, Celeron®

Chipset

Intel® B760 Express Chipset

Memory

4× DDR5 DIMM, up to 256 GB, Dual Channel
i9/i7: DDR5 5600/5200/4800/4400
i5/i3/12th Gen: DDR5 4800/4400
ECC/Non-ECC Unbuffered, XMP support

Graphics

Intel® HD Graphics
HDMI 2.1 (4096×2160@60Hz), DP 1.2 (4096×2304@60Hz)*Depends on CPU

Audio

Realtek® Audio CODEC, 2/4/5.1/7.1-channel, S/PDIF Out

LAN

Realtek® GbE LAN (1 Gbps/100 Mbps/10 Mbps)

Wireless

Intel® Wi-Fi 6E AX210, Bluetooth 5.3, 2.4/5/6 GHz, 160 MHz

Expansion Slots

CPU: 1× PCIe 5.0 x16
Chipset: 4× PCIe 3.0 x1

Storage

CPU: 1× M.2 PCIe 4.0 x4/x2 (22110/2280)
Chipset: 1× M.2 PCIe 4.0 x4/x2 (2280), 4× SATA 6Gb/sRAID 0/1/5/10

USB Ports

Rear: 1× USB-C 3.2 Gen 2x2, 1× USB 3.2 Gen 2 Type-A, 4× USB 2.0
Internal: 1× USB-C Gen 1, 2× USB 3.2 Gen 1, 4× USB 2.0

Internal I/O

24-pin ATX, 8-pin 12V, CPU fan, 4× system/pump fans
3× ARGB Gen2, 1× RGB
2× M.2, 4× SATA
Front panel, front audio, S/PDIF, USB headers, TPM, serial, reset, Clear CMOS, Q-Flash Plus

Back Panel

1× PS/2, 2× antenna, 1× USB-C 3.2 Gen 2x2, 1× USB 3.2 Gen 2 Type-A, 4× USB 2.0
1× HDMI, 1× DP, 1× RJ-45, 3× audio jacks

I/O Controller

iTE® I/O Controller Chip

Monitoring

Voltage, temperature, fan speed, water flow, fan fail, fan control

BIOS

128 Mbit AMI UEFI BIOSPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Features

GIGABYTE Control Center, Q-Flash, Q-Flash Plus, Smart Backup

Software

Norton® Internet Security OEM, LAN management

OS Support

Windows 11/10 64-bit

Form Factor

ATX (30.5 cm × 24.4 cm)
