Threadripper PRO 7995WX

Cut through intensive workloads by equipping your workstation with the AMD Ryzen Threadripper PRO 7995WX 2.5 GHz 96-Core sTR5 Processor. Built using the 5nm Zen 4 architecture with the sTR5 socket, this 96-core / 192-thread processor is designed to deliver accelerated performance for professionals such as artists, architects, engineers, and data scientists.

Key Features

96 Cores & 192 Threads
2.5 GHz Clock Speed
5.1 GHz Maximum Turbo Frequency
sTR5 Socket
384MB L3 Cache Memory
Eight-Channel DDR5 ECC Memory
128 PCIe 5.0 Lanes
Unlocked Processor
Enterprise-Grade Security & Management
AMD Zen 4 Architecture

With a 2.5 GHz base clock speed, a 5.1 GHz boost frequency, and 384MB of L3 cache, this CPU significantly reduces rendering times for 8K videos, high-resolution photos, and 3D models. You can overclock this processor for greater performance. The Ryzen Threadripper PRO 7995WX supports up to 128 PCI Express 5.0 lanes for high-speed throughput to compatible devices. It also supports eight-channel DDR5 ECC memory with up to 5200 MT/s transfer speeds that help run and multitask demanding applications efficiently.

Unmatched Performance

AMD Pro Technologies

Equipped with AMD Pro technologies, the Threadripper Pro 7000 WX-Series processor delivers an exceptional blend of performance, reliability, scalability and security required by modern businesses. AMD Pro security provides multilayered protection to secure sensitive data. AMD Pro Business Ready technologies deliver optimal long-term reliability, stability and a responsive user experience. Additionally, AMD Pro Manageability enables efficient IT administration by boosting deployment, imaging and remote management.

Maximise Your Productivity

Powerful Performance

Built to satisfy the requirements of artists, architects and engineers, the Threadripper Pro 7995WX is one of the fastest processors available, offering a highly expandable desktop or workstation. Designed specifically for those crucial moments when meeting a deadline is non-negotiable, this processor provides the performance professional's demand. It boasts unmatched, dependable full spectrum performance, complemented by enterprise-grade security features and manageability. Ultimately, it allows you to achieve more in less time, setting new standards for productivity.

Zen 4 Architecture

Thanks to the groundbreaking Zen 4 architecture, professionals across various industries can now experience unrivalled power, speed, performance, and efficiency. This advanced architecture significantly boosts processing capabilities, enabling professionals to work more efficiently. It effortlessly overcomes common lightly threaded and multithreaded bottlenecks with ease.

Expandability

Pushing the boundaries of expandability, the Threadripper Pro 7995WX caters to the diverse requirements of professionals across multiple industries, supporting a wide array of advanced workstation configurations. It empowers users to accelerate their workflows by seamlessly incorporating next-generation professional GPUs and high-speed storage devices.

Specifications

Platform	Desktop
Product Family	AMD Ryzen™ PRO Processors
Product Line	AMD Ryzen™ Threadripper™ PRO 7000 WX-Series
AMD PRO Technologies	Yes
Commercial Use	Yes
Regional Availability	Global
Former Codename	"Storm Peak"
Architecture	"Zen 4"
# of CPU Cores	96
Multithreading (SMT)	Yes
# of Threads	192
Max. Boost Clock	Up to 5.1GHz
Base Clock	2.5GHz
L1 Cache	6MB
L2 Cache	96MB
L3 Cache	384MB
Default TDP	350W
Processor Technology for CPU Cores	TSMC 5nm FinFET
Processor Technology for I/O Die	TSMC 6nm FinFET
CPU Compute Die (CCD) Size	71mm²
I/O Die (IOD) Size	388mm²
Package Die Count	13
Unlocked for Overclocking	Yes
AMD EXPO™ Memory Overclocking Technology	Yes
Precision Boost Overdrive	Yes
Curve Optimizer Voltage Offsets	Yes
CPU Socket	sTR5
Supporting Chipsets	WRX90, TRX50, Pro 695
CPU Boost Technology	Precision Boost 2
Instruction Set	x86-64
Supported Extensions	AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Thermal Solution (PIB)	Not included
Thermal Solution (MPK)	NA
Max. Operating Temperature (Tjmax)	95°C
Launch Date	10/19/2023
*OS Support	Windows 11 - 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit
Connectivity
USB Type-C® Support	No
Native USB 3.2 Gen 2 (10Gbps) Ports	4
Native SATA Ports	4
PCIe Express Version	PCIe 5.0
PCIe Lanes (Total/Usable/PCIe 5.0)	148 / 144 / 128
NVMe Support	Boot, RAID0, RAID1, RAID10, RAID5
System Memory Type	DDR5
Memory Channels	8
System Memory Subtype	RDIMM
System Memory Specification	Up to 5200MT/s
ECC Support	Yes (Default Enabled)
Graphics Capabilities
Integrated Graphics	No
Graphics Model	Discrete Graphics Card Required
USB Type-C® DisplayPort™ Alternate Mode	n/a

AMD Ryzen Threadripper PRO 7995WX 2.5 GHz sTR5 Processor, 96 Cores & 192 Threads, 5.1GHz Max Turbo Frequency, 384MB L3 Cache, 8-CH DDR5 ECC Memory, Up to 5200MT/s, Zen 4 Arc | 100-100000884WOF
