GIGABYTE B850 AORUS ELITE WIFI7 AM5 ATX Motherboard, AMD B850 Chipset, 4x DDR5 DIMM Slots, Up to 256GB Max Memory, WiFi & BT Connectivity, 1 x PCIe 5.0 x16, 3 x M.2 Slots | B850-A-ELITE-WF7

CPU Support

AMD Socket AM5, compatible with AMD Ryzen™ 9000, 8000, and 7000 Series Processors.

Chipset

AMD B850

Memory

- 4 x DDR5 DIMM slots, up to 256GB.
- Support for DDR5 speeds up to 8200 MT/s (O.C).
- AMD EXPO™ and XMP supported.

Integrated Graphics

- DisplayPort 1.4: Max resolution 3840x2160@144 Hz
- HDMI 1.4: Max resolution 1920x1080@30 Hz

Audio

Realtek® Audio CODEC, supporting up to 7.1 channels and S/PDIF Out.

LAN

Realtek® 2.5GbE LAN chip.

Wireless Communication

Realtek® Wi-Fi 7 RTL8922AE, supporting 802.11a/b/g/n/ac/ax/be on 2.4/5/6 GHz bands and Bluetooth 5.4.

Expansion Slots

- 1 x PCIe x16 slot (PCIe 5.0/4.0/3.0).
- 2 x PCIe x1 slots (PCIe 3.0).

Storage Interface

- 3 x M.2 slots (PCIe 5.0/4.0).
- 4 x SATA 6Gb/s connectors.
- RAID support: RAID 0, 1, 5 (Ryzen 9000 only), and 10.

USB Ports

- 1 x USB Type-C® (USB 3.2 Gen 2x2)
- 7 x USB 3.2 Gen 1/2
- 8 x USB 2.0/1.1

Back Panel

- 1 x DisplayPort
- 1 x Q-Flash Plus button
- 2 x USB 3.2 Gen 2 Type-A
- 2 x Antenna connectors
- 2 x audio jacks and S/PDIF Out.

I/O Connectors

Multiple headers for power, fans, RGB, TPM, and more.

BIOS

256 Mbit flash, AMI UEFI BIOS with Q-Flash and Q-Flash Plus.

Unique Features

Support for GIGABYTE Control Center (GCC), Smart Backup, Q-Flash, and more.

Bundled Software

Norton® Internet Security (OEM), LAN bandwidth management software.

Operating System

Windows 11 64-bit.

Form Factor

ATX, 30.5 cm x 24.4 cm.
