GIGABYTE B760M E DDR5 LGA1700 Micro ATX PC Case, Intel B760 Chipset, 2 x DDR5 DIMM / Up to 92GB Support, PCIe 4.0, 4* M.2, Realtek GbE LAN, HDMI / D-Sub / DP, USB-C | B760M-E

CPU Support

LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors

Chipset

Intel® B760 Express Chipset

Memory

Support for DDR5 memory modules up to 7200(O.C.) MT/s

2 x DDR5 DIMM sockets supporting up to 96 GB (48 GB single DIMM capacity) of system memory

Dual channel memory architecture

Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)

Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for Extreme Memory Profile (XMP) memory modules

Onboard Graphics

Integrated Graphics Processor-Intel® HD Graphics support with 1 x D-Sub port, 1 x DisplayPort, and 1 x HDMI port

Support for up to triple-display at the same time

Audio

Realtek® Audio CODEC supporting 2/4/5.1/7.1-channel audio

LAN

Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)

Expansion Slots

CPU: 1 x PCIe 4.0 x16 slot (PCIEX16)

Chipset: 1 x PCIe 3.0 x1 slot (PCIEX1)

Storage Interface

CPU: 1 x M.2 PCIe 4.0 x4/x2 (M2A_CPU)

Chipset: 1 x M.2 PCIe 4.0 x4/x2 (M2P_SB)

4 x SATA 6Gb/s connectors

USB

Chipset: 6 x USB 3.2 Gen 1 ports, 6 x USB 2.0/1.1 ports

Internal I/O Connectors

Various connectors including power, fan, LED, USB, M.2, SATA, front panel, audio, S/PDIF Out, USB headers, TPM header, serial port

Back Panel Connectors

2 x USB 2.0/1.1 ports, 1 x D-Sub port, 1 x DisplayPort, 1 x HDMI port, 4 x USB 3.2 Gen 1 ports, 1 x RJ-45 port, 3 x audio jacks

I/O Controller

iTE® I/O Controller Chip

H/W Monitoring

Voltage, temperature, fan speed, and water cooling flow rate detection

BIOS

128 Mbit flash BIOS with licensed AMI UEFI BIOS

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features

Support for GIGABYTE Control Center (GCC), Q-Flash

Bundled Software

Norton® Internet Security (OEM version), LAN bandwidth management software

Operating System

Support for Windows 11 64-bit, Windows 10 64-bit

Form Factor

Micro ATX Form Factor; 23.0cm x 21.5cm
